D60 Heavy Duty Cross-Over Steering Kit 3/4" Hole

WFO 1142HDA-34-KIT
Was: $319.00
Sale: $271.15
Save: 15%
Save: $47.85


D60 Heavy Duty Cross-Over Steering Kit for Kingpin Dana 60 Front Axles.  This cross-over steering kit comes with our heavy duty adjustable cross-over steer arm as well as an adjustable top plate for the driver's side.  The HDA steering arm and top plate eliminates the kingpin springs and replaces them with an adjustable set screw and jam nut to set kingpin pre-load.  As the kingpin bushing wears out, the pre-load can be adjusted tighter without taking anything apart.

We suggest running this heavy duty kit over the standard kit if you have 40" tires or larger. We also suggest using this kit if you are running offset rims, or bias ply tires.

For full off-road applications, we also suggest using our bronze upper bushings along with these arms.


This Kit includes:
WFO 1142HDA-34: D60 Heavy Duty Adjustable High Steer Arm, RH w/ 3/4" hole (Qty: 1)
WFO 1153: D60 High Steer Studs (Qty: 4)
WFO 1152: D60 High Steer Nuts (Qty: 4)
SSS-34F134P: 3/4-16 Set Screw For HDA Arms (Qty: 2)
WFO 3416-R: 3/4"-16 Jam Nut, Right Hand - 3/4"-16 Jam Nut, Right Hand (Qty: 2)
WFO 1140HDA: D60 Adjustable Cap (Qty: 1)
1095K65: Grease Zerk (Qty: 2)
WFO 1100-HDA: D60 3/8" Spacer For HDA Arms (Qty: 2)
DAN37307: D60 Kingpin Cap Gasket (Qty: 2)
BOLT, 1/2-20 x 2" Grade 5: Bolt, 1/2-20 x 2" Grade 5 (Qty: 4)
L WASHER, 1/2": Lock Washer, 1/2" (Qty: 4)
